Precision Leak Testing Systems for Better Production Yield.
Custom air leak, flow, and waterproof testing solutions for any production line where sealing integrity matters.
Die-Cast Housing & Battery Pack Sealing
4-channel simultaneous leak test for EV trays and motor housings — 23-second cycle, PLC-integrated.
View Case Study→
Catheter, Drug Vial & Flow Validation
Sub-SCCM flow and pressure decay testing for catheters and drug bottle seals — ISO 11608 validated.
View Case Study→
Touchscreen, Camera & IP68 Waterproofing
100% inline waterproof testing for smartphones and cameras — OK/NG differential pressure in 8 seconds.
View Case Study→
4-Channel Lens Module Airtightness
Simultaneous 4-channel airtightness for optical lens assemblies — micro-volume fixture, ±0.5% repeatability.
View Case Study→
Valve Body & Mechanical Part Sealing
Direct pressure testing for metal valves and hydraulic fittings — up to 4 MPa, production-line ready.
View Case Study→
Cabinet & Slide-Table Multi-Channel Systems
Unmanned cabinet and slide-table systems with multi-channel detection, barcode scan, and MES connectivity.
View Case Study→
Direct Pressure Tester
High-volume airtightness testing for housings, connectors, and sealed assemblies.
- Pressure: 0 – 1000 kPa
- Resolution: 0.001 kPa
- Cycle: ≤ 20 s
Differential Pressure Tester
High-sensitivity leak detection for tight-sealing precision components.
- Pressure: 0 – 1200 kPa
- Resolution: 0.01 kPa
- Sensitivity: 10× vs direct pressure
Mass Flow Tester
Flow rate and leakage detection for micro-channels, valves, and medical tubing.
- Flow: 0 – 50 L/min
- Resolution: 0.01 sccm
- Accuracy: ±1.0% RD
Auto-Regulating Tester
Intelligent pressure regulation for variable-volume parts and complex cavity testing.
- Auto pressure regulation
- 2-channel capable
- PLC / Fieldbus integration
Multi-Channel System
Simultaneous 2–4 channel testing for high-throughput production lines.
- 2 / 4 independent channels
- Independent threshold per channel
- Per-channel data logging
Embedded Module
Explosion-proof embedded tester for unmanned cabinet and automation line integration.
- ATEX-ready enclosure
- 24 VDC embedded module
- Cabinet & robot-line compatible
From Test Requirement to Production-Ready System
Our trusted B2B customization process ensures precision, reliability, and long-term value. Every solution is engineered to your exact specification.
Start Your Evaluation→Submit
Share your leak spec, pressure range, part drawings, and cycle time requirement.
Evaluation
Engineers review feasibility, select test method, and propose fixture concept.
Prototype
Sample parts validated with calibrated standard leaks and confirmed parameters.
Payment
Formal quotation confirmed, order placed, production scheduled.
Delivery
System shipped with fixture tooling, calibration cert, training, and 12-month warranty.
Figurtech systems cover low-pressure, direct-pressure, differential-pressure and flow-rate applications. Typical platforms support vacuum to 1200 kPa, with higher-pressure configurations available for metal valves and industrial parts. The right range and resolution are selected after reviewing your part volume, leak limit and cycle-time target.
Yes. Systems can be configured for PLC, RS-232/485, USB, Ethernet I/O, barcode scanners and MES data upload. Test results, OK/NG decisions, pressure curves and serial numbers can be stored for traceability.
Yes. We can provide standalone instruments, embedded modules, multi-channel cabinets, slide-table stations and fixture tooling for automated or semi-automated production lines.
Repeatability is controlled through stable pressure regulation, calibrated standard leaks, fixture sealing design, temperature compensation and validated test parameters. For production programs, we verify the setup with sample parts before formal delivery.
Yes. We supply fixture tooling, quick-seal connectors and calibrated standard leak references as part of a complete leak-test solution when required.
Lead time depends on the instrument platform, fixture complexity and validation requirements. Our engineers usually respond within one business day and provide remote support for setup, troubleshooting and production integration.
Let's Build Your Precision Testing Solution
Contact our engineers for a customized evaluation.
